OSQ High Output Series

AREA & FLOOD

The Cree Lighting OSQ High Output (HO) Area & Flood Light changes the standard for high output lighting. With high lumen output, one luminaire can replace multiple metal halide fixtures. This can result in more than 80 percent energy savings at exceptional performance levels. The OSQ High Output’s low profile design makes it easier to install while minimizing wind load requirements at the same time.

The 5000K version features TrueWhite Technology, which renders true-to-life colours with a CRI score of 90 and optical distributions that are optimized for automotive frontlines, large parking lots and high mast applications.

Direct mount, high mast & full-range adjustable brackets available. Contact us for more information!

Also available in Standard Wattage version: Cree Lighting OSQ

OUTDOORAll Outdoor• Area & Car Park• Security & Flood• Sports & Leisure
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output Gallery 02
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Cree Lighting OSQ High Output
Shown with High-Mast Accessories and Adjustable Bracket.
Features
  • Lumens
42,000L - 80,000L
  • Wattage
304W - 533W
  • CCT
3000K | 4000K | 5000K | 5700K
  • CRI
70 CRI | 90 CRI @ 5000K
  • Ratings
IP66 | IK08
  • Optics
Symmetric, Asymmetric
  • OPtions
NEMA, DALI
  • Warranty
10 Years
  • Highlight
Up to 80,000 lumens!
  • Highlight
NanoOptic® Precision Delivery
Benefits
  • Suitable upgrade for HID applications
  • Slim, low-profile design minimizes wind load requirements
  • Standard 10-year limited warranty
Colours
Notes
  • MOQ may apply for certain variations.
  • All lumen and wattage figures nominal.
  • *Not all variants available in all models.
Applications
Variations
PRODUCTVERSIONMOUNTINGOPTICLUMEN PACKAGECCTINSULATION CLASSVOLTAGECOLOURDIMMINGVARIANT
OSQ-HOHigh OutputE
Available Options:
- Direct
- High-Mast 		210Type II Short 1.0
2SHType II Short
2METype II Medium
3METype III Medium
4METype IV Medium
5METype V Medium
5SHType V Short
15D15° Flood
25D25° Flood
40D40° Flood
60D60° Flood
120D120° Flood
WSNWide Sign
AFAutomotive Frontline Optic		45L
65L		30K3000K - 70 CRI
40K4000K - 70 CRI
57K5700K - 70 CRI
50K5000K - 90 CRI		+Class I24220V-240V
12120V-240V		SVSilver
BKBlack		DIM1-10V Dimming
QField Adjustable Output
XX# Option
DLDALI		SStandard
FFuse
NNEMA 7 Pin Longjoin
[table “” not found /]

[table “” not found /]

Product Code Builder

Select your preferred product options below to generate and customise your product code.

  • Denotes non-standard option. May result in longer lead time. Contact ADLT for further information.

Selected Options

    Select options to see them here.

Product code

Waiting for selections...

Once completed, your product code will be displayed here and automatically added to the enquiry form below to assist with your enquiry.

Downloads

Brochures & Catalogues

Spec Sheets

IES & Design Files
